 Cone Crusher Application
Cone crusher is widely applied in metallurgical, construction,
road building, chemical and phosphatic industry. Cone crusher is suitable
for hard and mid-hard rocks and ores, such as iron ores, copper
ores, limestone, quartz, granite, gritstone, etc. Type of the
crushing cavity is decided by the application of the ores. Standard
type is for PYZ (secondary crush); middle type is for PYD (tertiary
crush); short-head type is for primary and secondary crush.
Cone Crusher Features
1. high productivity; high quality
2. less machine stop time
3. easy maintenance and low cost
4. unique crushing ability in primary, secondary and tertiary
crushing
Cone Crusher Structure & operation principles
Cone crusher consist of frame, transmission device, hollow eccentric
shaft, bowl-shaped bearing, crushing cone, springs and hydraulic
pressure station for adjusting discharge opening.
During operation, the motor drives the eccentric shaft shell to
turn around through ahorizontal axle and a pair of bevel gear.
The axle of crushing cone swings with the force of eccentric shaft
shell so that the surface of the crushing wall is close to the
roll mortar wall from time to time. In this way, the ores and
rocks will be pressed and crooked and crushed.
Cone Crusher Technique paramete
|
